MANUFACTURER / MODEL JOHNFORD MODEL SV-41 + DIVISOR YEAR 2004 CNC FANUC 18I MB TABLE DIMENSION 1.200 X 600 MM MAX WEIGHT ALLOWED ON TABLE 1.200 KG TRAVELS (X/Y/Z) 1.050 / 610 / 610 MM DISTANCE SPINDLE NOSE TO TABLE 100-710 MM. DISTANCE SPINDLE CENTER TO COLUMN 640 MM. RAPID FEED(X/Y) 30.000 MM./MIN. RAPID FEED(X/Y/Z) 20.000 MM./MIN. CUTTING FEED 12.000 MM/MIN. TAPER BT-40 SPINDLE SPEED 60-10.000 RPM SPINDLE POWER 7,5 / 11 KW AUTOMATIC TOOL CHANGER (ATC) INCLUDED ATC TYPE BIDIRECCIONAL RANDOM ATC POSITIONS 20 MAX TOOL DIAMETER 100 MM MAX TOOL LENGTH 320 MM MAX TOOL WEIGHT 10 KG EQUIPMENT INTERNAL COOLANT 20 BAR INCLUDED 2 LONGITUDINAL CHIP CONVEYOR INCLUDED CHIP CONVEYOR INCLUDED ELECTRICAL CABINET AIR CONDITIONING INCLUDED OTHERS MACHINE DIMENSIONS 2.990 X 3.420 X 2.888 MM. MACHINE APROX. WEIGHT 7.000 KG.

Description :
MANUFACTURER / MODEL JOHNFORD MODEL SV-41 + DIVISOR YEAR 2004 CNC FANUC 18I MB TABLE DIMENSION 1.200 X 600 MM MAX WEIGHT ALLOWED ON TABLE 1.200 KG TRAVELS (X/Y/Z) 1.050 / 610 / 610 MM DISTANCE SPINDLE NOSE TO TABLE 100-710 MM. DISTANCE SPINDLE CENTER TO COLUMN 640 MM. RAPID FEED(X/Y) 30.000 MM./MIN. RAPID FEED(X/Y/Z) 20.000 MM./MIN. CUTTING FEED 12.000 MM/MIN. TAPER BT-40 SPINDLE SPEED 60-10.000 RPM SPINDLE POWER 7,5 / 11 KW AUTOMATIC TOOL CHANGER (ATC) INCLUDED ATC TYPE BIDIRECCIONAL RANDOM ATC POSITIONS 20 MAX TOOL DIAMETER 100 MM MAX TOOL LENGTH 320 MM MAX TOOL WEIGHT 10 KG EQUIPMENT INTERNAL COOLANT 20 BAR INCLUDED 2 LONGITUDINAL CHIP CONVEYOR INCLUDED CHIP CONVEYOR INCLUDED ELECTRICAL CABINET AIR CONDITIONING INCLUDED OTHERS MACHINE DIMENSIONS 2.990 X 3.420 X 2.888 MM. MACHINE APROX. WEIGHT 7.000 KG.

Model No : SV-41 + DIVISOR

Get the Best Deals on Used / Second-Hand Machines for 'MANUFACTURER / MOJOHNFORD MODEL SV-41 + DIVISOR ' Jaggi & Jaggi Machines Tools is a trusted name in the Used machinery industry. Find here the best quality Used machines, Second Hand Machinery, we are leading dealers, suppliers & exporters from Mumbai India.
